Automatic cutting machine daily more prone to two types of failure

The clipping head is the clipping terminal action unit. The contents to be maintained every day are:

(1) using compressed air to blow the dust on the cutting knife pressure plate, with a soft cloth to clean the oil, if necessary, replace the pressure plate edge and the spiral cable, because may cause excessive pressure plate edge wear presser foot loose, resulting in cylinder damaged, replace the pressure plate edge should pay attention to when the pressure plate from the rotary bracket to loosen to forward along the spiral guide channel;

(2) check the wear of the cutting tool. When the effective width of the cutting knife is less than the set width must be replaced, otherwise it will cause fabric deformation; When replacing, pay attention to the penetration of the cutting knife. If the cutting knife penetrates too deep into the bristle brick, it will cause premature damage to the bristle brick, and there will be cutting quality problems in the last layer.

(3) clean the cutter guide rail and lubricate it. Check the position of the lifting shock absorber of the cutting tool to prevent the phenomenon that the vibration period of the cutting tool is too long and the position is too low and the cutting tool is broken;

(4) check the wear of the grinder belt and the grinder cable, clean the dust of the grinder arm and the pivot of the grinder, check the condition of the central grinder guide rail and the working clearance.

Cutting head moving carrier, daily maintenance content :

(1) check whether cutting area X to both sides of the sealing pressure plate is intact, there is no air leakage phenomenon, front and rear comb tooth plate fracture or distortion;

(2) with compressed air blowing? Take a soft cloth to clean the guide rail of cutting head, check the condition of X axis and Y axis transmission cable belt, lubricate the guide rail of X direction and Y direction cutting head;

(3) Check the damage of the bristle brick to ensure that there are no pits leading to the broken knife;

(4) check the status of cross bar pinion to ensure that there is no bending or deformation of comb teeth;

(5) Check the wear of the belt to ensure that there is no crack, deformation or distortion.

Maintenance of Control Cabinet The control cabinet is the central control center, which shall be maintained every day as follows :

(1) Vacuum air inlet and outlet grille. The cutting system has a total of 6 filter grilles, two grilles on each side cover plate, loosen the grilles from the grille seat to remove dust; On the maintenance and troubleshooting of automatic cutting machine to automatic cutting machine understanding, to ensure the maximum utilization of equipment. [br] Automatic cutting machine automatic cutting machine cutting head two of which are equipped with filters, filters must also remove dust;

(2) use the blower to remove the dust on the bracket, clean or replace the system box filter. Automatic cutting machine is more prone to two kinds of daily failures: one is the hardware failure, that is, the machine, equipment functional barriers, so that the automatic cutting machine can not work properly to play a role; The other is the fault of the software class, refers to the management system related to the operation of the automatic cutting machine, the operator of the operation of the automatic cutting machine. Usually the operator is not familiar with the common faults and troubleshooting methods, and does not respond to the treatment in time, which affects the production. Because the software type fault is relatively simple, it will not be elaborated here.

With the increasingly fierce competition among enterprises, enterprises should maintain their market advantages and pay attention to innovative technology while maintaining equipment to maximize the use of equipment, which requires all employees to participate in equipment management. The equipment maintenance and maintenance system management should take the comprehensive efficiency of equipment as the goal, the whole time and space system of equipment as the carrier, and the participation of all personnel as the basis, and do a good job of layered audit, so as to ensure the long-term and stable operation of automatic cutting machine and give play to the greater benefits of equipment.
