MS-8720MH Automatic Pocket Hemming Machine

MS-8720MH
全自动链式卷口袋机
Quantity:
Contact Now
add to cart

Description:

1.MS-8720MH:Lock stitch;

2.Sewing heads are driven by Hohsing direct drive;

3.Stepper motor controlled belt-feeding system, synchronous with the sewing head;

4.Stepper motor feeding assure no waves, curves or wrinkleless;

5.Flexible Transferring Wheel Adapting to Verities of Fabric Thickness Changes;

6.Thread trimming over sensor by cutter knife, 1 or 2 cuts depending the pocket distance;

7.Brother lockstitch with large capacity rotary hook;

8.Thread end, or thread break monitor;

9.Flexible Hemming Width Setting Mechanism;

10.Auto-Stacker, Auto-Cutter;


Application:


Efficiency:

Production : 500-800pcs/hour


Specification:

Machine Model
MS-8720MH
Machine Head Model
BROTHER:T8720C-05 / JUKI:MH380
Maxmum Sewing Speed
BR:3000Rpm / JK:5000Rpm
Needle Type
BR:DP*5 / JK:TV*7
Needle Gauge
1/8;3/16;5/16;3/8;1/2
Available Folders
8-12mm;12-15mm;15-18mm
Shuttle Type
Vertical half rotate 2 times capaticy
Thread Breakage Detection
Equipped
Motor
750W
Voltage
220V-240V Mono 50/60Hz
Air Pressure/Air Consumption
0.5MPa 3L/min
Machine NW
176KG
Machien GW
230KG
Machine Size
1225*950*1300mm
Package Size
1310*1110*1495mm
