MS-7300A-COIN Coin Pocket Setter Machine

MS-7300A-COIN
硬币口袋贴袋机
Quantity:
Contact Now
add to cart

Description:

1.Brother S 7300A sewing head, smooth & stable stitch guaranteed；

2.Easy moulds changing in only 15 minutes；

3.Cold-folding mechanism to maximumly improve efficiency；

4.Equipped with thread breakage detector；

5.Pocket folding / attaching / stacking in one operation for all kinds of fabrics，including stretch；

6.Big capacity rotary hook;

7.Laser indicators for correct positioning of the garment;

8.Data can be quickly transferred between different machines by USB;

Application:

Apply to Medium & Heavy Weight Fabric

Specification:

Machine Model
MS-7300A-COIN
Sewing Head
Brother S 7300A
Needles
DB*1
Max Sewing Speed
3500Rpm;Adviced 3000Rpm
Stitch length
1-6mm
Size of pockets
Min:60*60mm;Max:120*120mm
Stitching field
X-Y:170*160mm
Productivity
320 pockets or pocket facings/H
Voltage
220V-240V Monno 50/60Hz
Power
0.52Kw
Air pressure/Consumption
5.5Bar/65L/min
Dimensions mm L*W*H
1600*1400*1300
Weight(NW)
269Kg
Dimensions mm Packed L*W*H
1320*1520*1490
Weight(GW)
342Kg
